New CC Capstick and RC Angstor Capacitors

Introducing the industry's highest ripple current rating per C*V capacitors, ideally suited for bi-directional power conversion, high frequency AC, DC link, DC block, filtering and snubbing

Modern SMPS designs and PWM Chip innovations such as GaN based LLC LCC CLLLC push the frequency limitation further than the traditional buck or boost designs, consequently demanding more from the buck/boost capacitor or resonant capacitor. The unique demand of the Hi-Reliability resonant converter propelled Quantic™ Paktron to research, design and manufacture a new capacitor to address these challenges.

Resources

1-Page Overview

Whitepaper, Capacitor Selection for Hi-Rel CLLLC LLC LCC Resonant Converters

Capstick CC Data sheet

Angstor RC Data Sheet

Press Release
